Product Description

PT-125/180 semil-automatic flap disc machine is the automated equipment to produce flap disc, which can realize manually load backing pad, detection of backing pad, quantitative glue, blanking and slide arranging, shaping.

Technical data and price for PT-125/180 semi automatic flap disc machine:
Specification of flap disc
RSW-125 can make Φ100-125mm flap discs
RSW-180 can make Φ100-180mm flap discs
T27/T29,1leaf or 2leaf,leaf width 11-35mm
Manufacturing speed:8000pcs/10hours
Backing pad:Fiber glass or plastic
Power:Total 6kw,3phase,380v,50hz
Power source of the overall machine:Pneumatic and electric
Glue pump load:280kg
Glue system:AirTac air cylinder and SMC balance control valve
Glue-spread volume:4-30g(±0.02g)
Product row pieces count:it could arrange leaf at any point in 360 angle
Operator needed:1
Packing dimension:1.4x1x1.7m(main machine)+1.2x1x1.85m(glue system)
Packing volume:4.6CBM
Gross weight:900kg
Net weight:700kg

Payment Terms︰ TT

Product Image
